Module Serial Ports Submenu

Feature
Serial Port 0
I/O Base Address
Interrupt
PNP ID
Baudrate
Serial Port 1
I/O Base Address
Interrupt
PNP ID
Baudrate
11.4.4

Hardware Health Monitoring Submenu

Feature
CPU Temperature
Board Temperature
12V Standard
5V Standby
Input Current (12V Standard)
CPU Fan Speed
Copyright © 2013 congatec AG
Options Description
Disabled Enable or disable module serial port 0.
Enabled
3F8h, 2F8h, 220h, Set serial port base address.
228h, 238h, 2E8h,
338h, 3E8h
None, IRQ3, IRQ4, Set serial port interrupt.
IRQ5, IRQ6, IRQ10,
IRQ11, IRQ14, IRQ15
None Set serial port ACPI ID.
PNP0501
CGT0501
2400, 4800, 9600, Set serial port initial baudrate.
19200, 38400, 57600,
115200
Disabled Enable or disable module serial port 1.
Enabled
3F8h, 2F8h, 220h, Set serial port base address.
228h, 238h, 2E8h,
338h, 3E8h
None, IRQ3, IRQ4, Set serial port interrupt.
IRQ5, IRQ6, IRQ10,
IRQ11, IRQ14, IRQ15
None Set serial port ACPI ID.
PNP0501
CGT0501
CGT0502
2400, 4800, 9600, Set serial port initial baudrate.
19200, 38400, 57600,
115200
Options Description
no option Displays the actual CPU temperature in °C.
no option Displays the actual module board temperature in °C
no option Displays the actual voltage of the 12V standard power supply.
no option Displays the actual voltage of the 5V standby power supply.
no option Displays the module's input current from 12V standard voltage.
no option Displays the actual CPU fan speed in RPM.
