The setup program uses a key-based navigation system. Most of the keys can be used at any time while in setup. The table below explains the
supported keys:
Key
j i Left/Right
k l Up/Down
+ - Plus/Minus
Tab
F1
F2
F9
F10
ESC
ENTER
8.3

Main Setup Screen

When you first enter the BIOS setup, you will see the main setup screen. The main setup screen reports BIOS, processor, memory and board
information and is for configuring the system date and time. You can always return to the main setup screen by selecting the 'Main' tab.
Feature
Main BIOS Version
OEM BIOS Version
Build Date
Product Revision
Serial Number
BC Firmware Revision
MAC Address (1
Ethernet)
st
MAC Address (2
Ethernet)
nd
Boot Counter
Running Time
Microcode Patch
Copyright © 2016 congatec AG
Description
Select a setup menu (e.g. Main, Boot, Exit).
Select a setup item or sub menu.
Change the field value of a particular setup item.
Select setup fields (e.g. in date and time).
Display General Help screen.
Load previous settings.
Load optimal default settings.
Save changes and exit setup.
Discard changes and exit setup.
Display options of a particular setup item or enter submenu.
Options
No option
No option
No option
No option
No option
No option
No option
No option
No option
No option
No option
Description
Displays the main BIOS version.
Displays the additional OEM BIOS version.
Displays the date the BIOS was built.
Displays the hardware revision of the board.
Displays the serial number of the board.
Displays the firmware revision of the congatec board controller.
Displays the MAC address of the onboard Ethernet controller.
Displays the MAC address of the onboard Ethernet controller.
Displays the number of boot ups.
Note: The value is limited to 16777215.
Displays the board-runtime in hours.
Note: The value is limited to 65535.
Displays the processor's microcode revision.
IA40m12.indd
58/97
