Motor list

Asynchronous
motors 1PH7(=PA6) /
1PL6 / 1PH4
Input in Motor order
P097 number
(MPRD)
1 1PH7101-2_F_
2 1PH7103-2_D_
3 1PH7103-2_F_
4 1PH7103-2_G_
5 1PH7105-2_F_
6 1PH7107-2_D_
7 1PH7107-2_F
8 1PH7131-2_F_
9 1PH7133-2_D_
10 1PH7133-2_F_
11 1PH7133-2_G_
12 1PH7135-2_F_
13 1PH7137-2_D_
14 1PH7137-2_F_
15 1PH7137-2_G_
16 1PH7163-2_B_
17 1PH7163-2_D_
18 1PH7163-2_F_
19 1PH7163-2_G_
20 1PH7167-2_B_
21 1PH7167-2_D_
22 1PH7167-2_F_
23 1PH7184-2_B_
24 1PH7184-2_D_
25 1PH7184-2_F_
26 1PH7184-2_L_
27 1PH7186-2_B_
28 1PH7186-2_D_
29 1PH7186-2_F_
30 1PH7186-2_L_
31 1PH7224-2_B_
32 1PH7224-2_D_
33 1PH7224-2_U_
9-42
Rated Frequency Current
speed f n [Hz]
n n [rpm]
1750 60.0
1150 40.6
1750 60.95
2300 78.8
1750 60.0
1150 40.3
1750 60.3
1750 59.65
1150 39.7
1750 59.65
2300 78.0
1750 59.45
1150 39.6
1750 59.5
2300 77.8
400 14.3
1150 39.15
1750 59.2
2300 77.3
400 14.3
1150 39.1
1750 59.15
400 14.2
1150 39.1
1750 59.0
2900 97.4
400 14.0
1150 39.0
1750 59.0
2900 97.3
400 14.0
1150 38.9
1750 58.9
Voltage Torque
I n [A] U n [V] M n [Nm]
9.7 398
9.7 391
12.8 398
16.3 388
17.2 398
17.1 360
21.7 381
23.7 398
27.5 381
33.1 398
42.4 398
40.1 398
40.6 367
53.1 357
54.1 398
28.2 274
52.2 364
69.0 364
78.5 398
35.6 294
66.4 357
75.2 398
49.5 271
87.5 383
120.0 388
158.0 395
67.0 268
116.0 390
169.0 385
206.0 385
88.0 268
160.0 385
203.0 395
6SE7087-2JD60
Operating Instructions
05.2006
cos ϕ
i
µ
[%]
23.5 0.748 58.3
35.7 0.809 51.8
34 0.835 41.3
31 0.791 50.4
43.7 0.773 54.1
59.8 0.807 51.4
54.6 0.802 48.8
71 0.883 34.2
112 0.853 46.2
95.5 0.854 41.1
93 0.858 40.4
117 0.862 40.3
162 0.855 45.8
136 0.848 43.0
120 0.866 39.3
227 0.877 40.4
208 0.841 48.7
185 0.855 41.2
158 0.781 55.3
310 0.881 39.0
257 0.831 50.9
224 0.860 40.3
390 0.840 52.5
366 0.820 48.0
327 0.780 52.9
267 0.800 48.7
505 0.810 58.3
482 0.800 50.4
465 0.800 50.0
333 0.780 52.0
725 0.870 41.5
670 0.810 49.4
600 0.840 43.4
