Siemens Vector Control Operating Instructions Manual page 249

05.2006
Line voltage 3 AC 380 V to 480 V
Order No. Rated input
current cross-section Recommended fuse
6SE70... VDE
[A] [mm²]
16-1EA61 6.1 1.5
18-0EA61 8.0 1.5
21-0EA61 10.2 2.5
21-3EB61 13.2 2.5
21-8EB61 17.5 4
22-6EC61 25.5 10
23-4EC61 34 16
23-8ED61 37.5 16
24-7ED61 47 25
26-0ED61 59 25
27-2ED61 72 50
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES
Line side
AWG gR (SITOR) gL lvhrc
[A] 3NE [A]
16 − − − − 10
− − − −
16 16
− − − −
14 16
14 25 1815-0 25
10 25 1815-0 25
6 35 1803-0 35
4 40 1802-0 50
4 63 1818-0 63
2 63 1818-0 63
2 80 1820-0 100
00 80 1820-0 100
Operating Instructions
North America
3NA Type [V]
3803 AJT, LPJ 600
3805 AJT, LPJ 600
3805 AJT, LPJ 600
3810 AJT, LPJ 600 17.5 3500-
3810 AJT, LPJ 600
3814 AJT, LPJ 600
3820 AJT, LPJ 600
3822 AJT, LPJ 600
3822 AJT, LPJ 600
3830 AJT, LPJ 600
3830 AJT, LPJ 600
Connecting-up
Motor side
Line reactor
cross-section
VDE
[A] 4EP.. [mm²]
8 1.5
3200-
1US00
12 1.5
3400-
2US00
15 1.5
3400-
1US00
2.5
0US00
25 2.5
3600-
4US00
35 10
3600-
5US00
45 10
3700-
2US00
50 16
3700-
5US00
60 16
3800-
2US00
80 16
3800-
7US00
90 25
3900-
2US00
7-5
AWG
16
16
16
14
14
6
6
4
4
4
2
