Parameterizing Steps
P104=? P105=?
P106=?
P107 = ?
P108 = ?
P109 = ?
P113 = ?
P100=0,1,2 P100 = 3,4,5
P100>2
P100=1,2
P114 = ?
P115 = 1
9-54
IEC motor: Cos (phi) as per rating plate
NEMA motor: rated output [Hp]
(Group drives: total of all output ratings)
NEMA motor: Enter the motor efficiency in %
as per rating plate
Enter the rated motor frequency in Hz
as per rating plate
Enter the rated motor speed in rpm
as per rating plate
Enter the motor pole pair number
(This is calculated automatically)
Enter the rated motor torque in Nm
as per rating plate or motor catalog (this is only used for
normalizing the process data and visualization parameters)
WARNING!
INCORRECT SETTINGS CAN BE DANGEROUS!
Process-related conditions for closed-loop control
0: Drive for standard applications (e.g. pumps)
1: Drive with strong torsion, gear play, large moments of inertia
(e.g. paper machine)
2: Drive for very dynamic accelerations (without load inertia)
(e.g. shears)
3: Drive for strong schock stressing (e.g. roll drive)
4: Drive with high smooth running characteristics at low speeds.
5: Drives with modest response requirements, which can be
optimized in their efficiency with frequent part-load operation.
6: Drive with high starting torque.
7: Dynamic torque response in field-weakening range
See next section for description
Calculate motor model for "Automatic parameterization"
Reference values P350 to P354 are set to the rated motor
values.
The motor parameters and controller settings are calculated.
