05.2006
G-type rail according to EN50035
350 mm
Side view
G-type rail according to EN50035
350 mm
Side view
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES
Mounting surface
Type A
Front view (without front panel)
Fig. 5-2 Dimension drawings for installation of types A, B
Mounting surface
Type C
Front view (without front panel)
Fig. 5-3 Dimension drawings for installation of types C, D
Operating Instructions
Cutouts for
M6 screws
45 mm
90 mm
Type B
Cutouts for
M6 screws
90 mm 45 mm
180 mm 180 mm
270 mm
Type D
Installation
67.5 mm
135 mm
5-3
