Aux. power
supply
150 mA
Out
Bidirectional
digital inputs-
and outputs
I ≤ 20 mA
out
Outputs
Digital inputs
Ri = 3,4 kΩ
Inputs
Serial interface 2
USS (RS485)
Reference potential RS485
Reference voltage
P10 V / N10 V
I ≤ 5 mA
Analog input 1
(non-floating)
11 bit + sign
U: R = 60 kΩ
in
I: R = 250 Ω
in
(Close S3)
Analog input 2
(non-floating)
Analog output 1
10 bit + sign
U: I ≤ 5 mA
I: R ≤ 500 Ω
Analog output 2
*) Contact assignment according to switch design, see section "Switch settings"
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES
X101
Controller
1
P24V
2 M24
3
In
4
Out/In
5
24V
6
4 bidirectional digital inputs/outputs
7
24V
8
24V
9
24V
RS485P
10
RS485N
11
12
S2
X102 Switch for USS bus connection
P10 AUX
13
N10 AUX
14
15
S3
1 2
*)
16
17
S3
3 4
*)
18
19
20
M
21
22
M
Fig. 7-6 Overview of the standard connections
