Switch settings for
DipFix switch
design
Switch settings for
slide switch design
NOTE
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES
Switch
S1
•
open
• closed
S2
•
open
• closed
S3 (1,2)
• open
• closed
S3 (3,4)
• open
• closed
S4 (1,2,3)
• Jumper 1, 3
•
Jumper 2, 3
S4 (4,5,6)
• Jumper 4, 6
•
Jumper 5, 6
Switch Contact Status
S1 1-4 open
S1 1-4 closed
S2 2-3 open
S2 2-3 closed
S3 1-4 open
S3 1-4 closed
S3 2-3 open
S3 2-3 closed
S41 1-2 closed
S41 2-3 closed
S42 1-2 closed
S42 2-3 closed
Contacts S41 (4, 5, 6) and contacts S42 (4, 5, 6) are not used.
Operating Instructions
Meaning
SCom1 (X300): Bus terminating resistor
•
Resistor open
• Resistor closed
SCom2 (X101/10,11): Bus terminating resistor
•
Resistor open
• Resistor closed
AI1: Changeover current/voltage input
• Voltage input
• Current input
AI2: Changeover current/voltage input
• Voltage input
• Current input
AO1: Changeover current/voltage output
• Voltage output
•
Current output
AO2: Changeover current/voltage output
• Voltage output
•
Current output
Meaning
Bus terminating resistor open
Bus terminating resistor closed
Bus terminating resistor open
Bus terminating resistor closed
AI1: Voltage input
AI1: Current input
AI2: Voltage input
AI2: Current input
AO1: Current output
AO1: Voltage output
AO2: Current output
AO2:Voltage output
