05.2006
NOTA
Targa di tipo
Siemens AG
6SE7087-2JD60
SIMOVERT MASTERDRIVES
Il Derating della corrente nominale ammissibile per altezze di
installazione oltre 1000 m per temperature ambiente sotto i
40 °C può essere calcolato come segue:
derating totale = Derating
K = K
x K
1
2
Si deve fare attenzione, che il derating totale non può essere maggiore
di 1!
Esempio:
altezza: 3000 m
temperatura ambiente: 35 °C
⇒ derating totale = 0,845 x 1,125 = 0,95
Fig. 13-2
Targa di tipo
Istruzioni di servizio
x Derating
altezza
temperatura ambiente
Dati tecnici
K
= 0,845
1
K
= 1,125
2
indicazione apparecchio
elenco delle
opzioni dell'apparecchio
anno di produzione
mese di produzione
13-3
