Key
ON key
OFF key
Reversing key
Toggle key
Raise key
Lower key
Hold toggle key
and depress raise
key
Hold toggle key
and depress lower
key
SIEMENS AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES
Meaning
•
For energizing the drive (enabling motor activation).
•
If there is a fault: For returning to fault display
•
For de-energizing the drive by means of OFF1, OFF2 or OFF3
(P554 to 560) depending on parameterization.
•
For reversing the direction of rotation of the drive.
The function must be enabled by P571 and P572
•
For switching between parameter number, parameter index
and parameter value in the sequence indicated (command
becomes effective when the key is released).
•
If fault display is active: For acknowledging the fault
For increasing the displayed value:
•
Short press = single-step increase
•
Long press = rapid increase
For lowering the displayed value:
•
Short press = single-step decrease
•
Long press = rapid decrease
•
If parameter number level is active: For jumping back and forth
between the last selected parameter number and the
operating display (r000)
•
If fault display is active: For switching over to parameter
number level
•
If parameter value level is active: For shifting the displayed
value one digit to the right if parameter value cannot be
displayed with 4 figures (left-hand figure flashes if there are
any further invisible figures to the left)
•
If parameter number level is active: For jumping directly to the
operating display (r000)
•
If parameter value level is active: For shifting the displayed
value one digit to the left if parameter value cannot be
displayed with 4 figures (right-hand figure flashes if there are
any further invisible figures to the right)
Table 8-4 Operator control elements on the PMU
