Siemens Vector Control Operating Instructions Manual page 427

05.2006
Number / Alarm Cause
A045 The DC braking function has been activated
and the motor frequency is still above the
DC braking activated frequency at which DC braking begins (P398).
A049 At serial I/O (SCB1 with SCI1/2), no slave is
connected or fiber-optic cable is interrupted or
No slave slaves are without voltage.
A050 At ser. I/O the slaves required according to a
parameterized configuration are not present
Slave incorrect (slave number or slave type): Analog inputs or
outputs or digital inputs or outputs have been
parameterized which are not physically
present.
A051 In a peer-to-peer connection a baud rate has
been selected which is too high or too
Peer baud rate different.
A052 In a peer-to-peer connection, a PcD length has
been set which is too high (>5).
Peer PcD L
A053 In a peer-to-peer connection, the pcD length of
transmitter and receiver do not match.
Peer Lng f.
A057 Occurs when a TB is logged on and present,
but parameter tasks from the PMU, SCom1 or
TB Param SCom2 have not been answered by the TB
within 6 seconds.
A061 An active signal is present at binector U065
(1).
Alarm 1
Function blocks
A062 An active signal is present at binector U066
(1).
Alarm 2
Function blocks
A063 An active signal is present at binector U067
(1).
Alarm 3
Function blocks
A064 An active signal is present at binector U068
(1).
Alarm 4
Function blocks
A065 The auto restart option (P373) restarts the
drive. A possibly parameterized power-up
Auto restart active delay time (P374) expires if flying restart is not
selected. During pre-charging of the DC link,
there is no time monitoring i.e. with an external
electronics power supply, it is also switched-in
again.
A066 The measured target frequency of the external
converter (or supply) is greater than the
fsyn > fmax parameterized maximum frequency of the
synchronizing converter.
A067 The measured target frequency of the external
converter (or supply) is less than the minimum
fsyn < fmin frequency required for synchronizing.
A068 The setpoint frequency of the synchronizing
converter deviates too significantly from the
fsyn<>fsoll measured target frequency of the external
converter (or supply). The permissible
deviation can be set in P529.
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions
Counter-measure
- Increase frequency at which DC braking
begins
P690 SSCI AnaIn Conf
- Check slave.
- Check cable.
Check parameter P693 (analog outputs), P698
(digital outputs). Check connectors
K4101...K4103, K4201...K4203 (analog inputs)
and binectors B4100...B4115, B4120...B4135,
B4200...B4215, B4220...B4235 (digital inputs)
for connecting.
Adjust the baud rate in conjunction with the
SCB boards P701 SCom/SCB Baud Rate
Reduce number of words P703 SCom/SCB
PcD #
Adjust the word length for transmitter and
receiver
P703 SCom/SCB PcD #
Replace TB configuration (software)
Check cause of alarm (see FD 710)
Check cause of alarm (see FD 710)
Check cause of alarm (see FD 710)
Check cause of alarm (see FD 710)
Caution!
Personnel could be in danger when the drive
automatically restarts. Check whether the auto
restart function is really required!
Check:
- P452 n/f(max, FWD Spd)/ P453 n/f(max,REV
Spd) are correct and
- correct motor data set P578 Src MotDSet
Bit0 are selected
Check:
- r533 Sync Target Freq
- Synchronizing cable.
Adjust total setpoint (main and additional
setpoints) to the target frequency displayed in
visualization parameter r533.
Faults and Alarms
14-21
