Parameterizing Steps
Parameter description
P038.1 DispTorqConn.r39.1
P038.1 DispTorqConn.r39.2
P040.1 DispSpdConn.r41.1
P040.2 DispSpdConn.r41.2
P040.3 Disp Freq Conn.r41.3
P042.1 Disp Freq Conn.r43.1
P042.2 Disp Freq Conn.r43.2
P042.3 Disp Freq Conn.r43.3
9.2.2

Parameterizing with user settings

NOTE
P060 = 2
P366 = ?
P970 = 0
Unit carries out parameter
reset and then leaves the
"Fixed settings" menu
9-38
P100 = 0 P100 = 1
V/f + n V/f
-
-
Setp CP Setp CP
KK0148 KK0148
-
Setp CP Setp CP
KK0148 KK0148
KK0199 KK0199
During parameterization by selecting user-specific fixed settings, the
parameters of the unit are described with values which are permanently
stored in the software. In this manner, it is possible to carry out the
complete parameterization of the units in one step just by setting a few
parameters.
The user-specific fixed settings are not contained in the standard
firmware; they have to be compiled specifically for the customer.
If you are interested in the provision and implementation of fixed
settings tailored to your own requirements, please get in contact with
your nearest SIEMENS branch office.
Select "Fixed settings" menu
Select desired factory setting
0...4: Factory settings
5: User setting 1 (currently as P366 = 0)
6: User setting 2 (currently as P366 = 0)
:
10: Lift and lifting equipment
Start parameter reset
0: Parameter reset
1: No parameter change
Fig. 9-3 Sequence for parameterizing with user settings
P100 = control type
P100 = 2 f-Reg.
Textile (P587 = 0)
- -
- -
Setp CP Setp CP
KK0148 KK0148
- - KK0091
Setp CP Setp CP
KK0148 KK0148
KK0199 KK0091
