Setting RF Power

The RF radius of a configuration can be limited to allow another MXW system to re-use the frequency time-slots. It is best
practice to use the lowest setting that supports the installation. Perform a walk-around test with the transmitters to ensure
that the coverage setting is sufficient.
The RF Power is set from the Preferences tab of the control software. The setting applies to each access point in the
Configuration. Reference the following table for setting the RF Power.
RF Power Levels
Setting Transmitter Power (mW)
Max 80
High 16
Medium (default) 3
Low 1
65
Coverage Distance from APT
150 ft
100 ft
50 ft
25 ft
a
Room A Room B
RF Coverage
Typical Application
Ballroom and auditorium spaces
Large meeting spaces and lecture halls
Conference, training and multipurpose
rooms
Small video-conference rooms and
boardrooms
Room C Room D
