Shure Microflex Wireless User Manual page 85

Software
Preferences Tab
①
②
③
⑤
① Language
Selects the language for the control software when the ANI
is in Standalone Mode. In Standalone Network mode, this is
defined in the MXW System control software.
② Device Serial Number
Displays the device serial number.
③ Firmware Version
Displays the current firmware version of the device.
④ Reset Button
Reboots the device with factory default settings.
⑤ Register This Product Link
Click to register the device at www.shure.com to receive
product and software updates.
⑥ Audio Routing Mode
• MXW Mode: Enables automatic channel routing when the
device is a part of an MXW group (assigned from the MXW
System control software).
• Standalone Mode: Channels must be routed manually with
Dante Controller software.
⑦ Device Name
Device names can be customized with up to 31 characters,
except '=','.' or '@'.
85
⑥
⑦
⑧
⑩
⑧ Addressing Mode
Auto: IP settings are Link-Local or automatically accepted
from a DHCP server.
Manual: IP settings (IP Address, Subnet Mask, and
Gateway) are static and are entered manually.
⑨ MAC Address
Unique identifier assigned to each network interface.
⑩ Port 4 Mode
Configures the Port 4 of the network interface:
• Switched Mode (default): Full Ethernet support on port 4.
• Uplink Mode: Only control data is transported. Multicast
traffic for Dante digital audio and the Shure Web Device
Discovery application is restricted.
⑪ Front Panel Lockout
Disables the front panel controls on the hardware.
Channels can still be selected for monitoring at the
headphone jack.
⑫ Password
The default password for the device is 'admin'.
• Admin (default): Full editing rights. The Admin can enable or
disable a Tech-level logon.
• Tech: Rights are limited to the Inputs/Outputs page
(hardware functions only).
• Guest: Monitoring only.
⑪
⑫
