System Setup

Channel Routing between Devices

Channels are routed when charging stations and output devices are selected to fill the APT group (2-, 4-, or 8-channels).
Once the devices are selected for the group, the channels are mapped between the charging slots, audio outputs and the
wireless receiver.
Group selections are made from the Configuration tab of the control interface.
Each group has two selections available for charging stations and audio output devices. The selections determine the
51
charging stations (A and/or B)
Group Selections Determine Routing
channel routing in the group.
1 2 3 4 5 6 7 8
push to solo | hold to mute
push to solo | hold to mute
push to solo | hold to mute
audio output devices (A and/or B)
HEADPHONE
