Microflex Wireless Specifications

MXW6 Boundary Transmitter

Microphone Capsule
MXW6/O
MXW6/C

MXW8 Gooseneck-Base Transmitter

Microphone Connector
6-pin connector for Shure MX405/10/15
Configuration
Unbalanced
Input Impedance
@ 1 kHz
>20 kΩ

Access Point Transceiver (APT)

Network Interface
RJ45: Gigabit Ethernet, Dante digital audio
Plenum Rating
UL 2043
Power Requirement
Power over Ethernet (PoE) Class 0, 6.5W
Antenna Type
Internal, Spatial Diversity, Circular Polarization
Antenna Gain
Average
Peak
Housing
Molded Plastic, Cast Zinc
Dimensions
24 mm x 170 mm x 170 mm (1.35 in. x 6.7 in. x 6.7 in.), H
x W x D
Without mounting plate or cover
99
R183B
R185B
0.5 dBi
3.0 dBi
Dimensions
23 mm x 44 mm x 114 mm (0.9 in. x 1.75 in. x 4.5 in.) H x
W x D
Weight
108 g (3.8 oz.)
with batteries
Gooseneck Options
See accessories list
Dimensions
36 mm x 71 mm x 124 mm (1.4 in. x 2.8 in. x 4.9 in.) H x
W x D
Weight
193 g (6.8 oz.)
with batteries, without microphone
Weight
APT8
APT2, APT4
Paintable Cover
Mounting Bracket
856 g (1.9 lbs)
845 g (1.9 lbs)
85 g (0.2 lbs)
68 g (0.15 lbs)
