Hardware Description
⑧ TQG Connector
The MXW hybrid bodypack has a TQG connector for an
external lavalier or headset microphone.
⑩ Internal Microphone
The bodypack transmitter has an internal, omnidirectional
microphone that can be set to automatically engage when
not connected to a lavalier microphone.
Status LED Table
Status LED
Active Green
Mute Red
Red
Pulsing
Standby
(long off,
short on)
Flashing
Identify
Yellow
21
Description
Ready to pass audio to
network.
Audio is muted.
Audio is muted and the
transmitter is in a hibernation
state to conserve the battery.
The Identify button has been
pressed from the control
software.
Status LED
Red
Out of RF
Pulsing
Coverage
(short on/
Range
off)
Charging Off
Battery
Flashing
Statistics
Yellow
Reset
Two
microphones Red
trying to Pulsing
connect to (long on,
same audio short off)
channel
Off Off
Description
The transmitter is out of the
RF coverage range to the
linked access point.
The transmitter is charging.
Battery statistics have been
reset for the transmitter.
Only one microphone for each
audio channel can be active
at a time.
No connection to the network.
The transmitter must be
turned on using the power
button on the mic.
