Microflex Wireless Specifications

Transmitters

Gain Adjustment Range
−25 to +15 dB (in 1 dB steps)
Maximum Input Level
Mic gain @ −16 dB
−9 dBV
Headphone Output
3.5 mm (1/8"), dual mono (will drive stereo phones)
Maximum Headphone Output Power
1kHz @ 1% distortion, peak power, @16Ω
17.5 mW
Antenna Type
Internal, Spatial Diversity, Linear Polarization
Antenna Gain
Average
Peak

MXW1 Hybrid Bodypack Transmitter

Microphone Connector
4-Pin male mini connector (TA4M), See drawing for details
Input Impedance
@ 1 kHz
>20 kΩ
Internal Microphone
Omnidirectional (20 Hz – 20 kHz)

MXW2 Handheld Transmitter

Microphone Capsule
SM58, SM86, Beta58, VP68
Configuration
Unbalanced
Input Impedance
@ 1 kHz
>20 kΩ
98
-1.1 dBi
0.5 dBi
Battery Type
Rechargeable Li-Ion
Battery Life
MXW1, MXW6, MXW8
MXW2
Calculated with a new battery. Runtimes vary depending on
battery health.
Charge Connector
USB 3.0 Type A
Housing
Molded Plastic
Recommended Storage Temperature Range
0°C (32°F) to 25°C (77°F)
Dimensions
22 mm x 45 mm x 99 mm (0.9 in. x 1.8 in. x 3.9 in.) H x W
x D
Weight
85 g (3.0 oz.)
with batteries, without microphone
Dimensions
226 mm x 51 mm (8.9 in. x 2.0 in.) L x Dia.
including SM58 microphone capsule
Weight
323 g (11.4 oz.)
with batteries, including SM58 microphone capsule
Up to 9 hours
Up to 15 hours
