System Setup

Group Devices to Form Audio Channels

Use the group configuration to form the audio channel between the microphone, the access point (APT), charger and
audio output device. The audio channel establishes the audio routing, RF coordination, and data control for a set of
devices. Groups are comprised of networked devices (set to the same subnet). A component can belong to one group at a
time.
Start with the APT and select the corresponding devices:
• Chargers: for linking microphones
• Audio outputs: for routing audio to analog outputs
APT8-1
ANI8-1
NCS8-1
APT8-2
ANI8-2
NCS8-2
APT4-3
ANI4-3
NCS4-3
Once the group formed, microphones can be linked to channels using the charging station.
47
Form the group by selecting devices
from the network.
push to solo | hold to mute
push to solo | hold to mute
push to solo | hold to mute
Channels are mapped between the
devices selected for the group.
Group Components from the Network
APT8-1
push to solo | hold to mute
APT8-2
push to solo | hold to mute
push to solo | hold to mute
APT4-3
NCS8-1
NCS4-3
ANI8-1
ANI8-2
ANI4-3
NCS8-2
