Canon imagePROGRAF iPF8000S User Manual page 132

Paper
Paper size
DIN C1
DIN C2
DIN C3
DIN C4
20"x24"
18"x22"
14"x17"
12"x16"
10"x12"
10"x15"
8"x10"
US Photo 16"x20"
Poster 20"x30"
Poster 30"x40"
Poster 42"x60"
Poster 44"x62"
13"x22"
Poster 300x900mm
Custom Paper Size
Note
•
In the printer driver, paper sizes are categorized into groups based on the "size system" such as ISO
A or ANSI.
In Windows and Mac OS 9, some size systems are not available by default. Follow the steps below to
make them available.
Windows:
1.
Display the printer driver dialog box.
2.
Click the Page Setup tab to display the Page Setup sheet.
3.
Click Size Options to display the Paper Size Options dialog box.
4.
Select the Display Series check box.
Mac OS 9:
1.
In Chooser, choose GARO Printer Driver.
2.
Choose Page Setup from the application menu to display the dialog box for page settings.
3.
Click Media Design in the Page Attribute list to display the Media Design pane.
4.
Select the Display Series check box.
•
For details on non-standard paper sizes, see "Printing on Non-Standard Paper Sizes". (→P.364)
•
Borderless printing is not supported on sheets.
116 Handling Paper
648.0 × 917.0 mm (25.51 × 36.10 in)
458.0 × 648.0 mm (18.03 × 25.51 in)
324.0 × 458.0 mm (12.76 × 18.03 in)
229.0 × 324.0 mm (9.02 × 12.76 in)
508.0 × 609.6 mm (20.00 × 24.00 in)
457.2 × 558.8 mm (18.00 × 22.00 in)
355.6 × 431.8 mm (14.00 × 17.00 in)
304.8 × 406.4 mm (12.00 × 16.00 in)
254.0 × 304.8 mm (10.00 × 12.00 in)
254.0 × 381.0 mm (10.00 × 15.00 in)
203.2 × 254.0 mm (8.00 × 10.00 in)
406.4 × 508.0 mm (16.00 × 20.00 in)
508.0 × 762.0 mm (20.00 × 30.00 in)
762.0 × 1016.0 mm (30.00 × 40.00 in)
1066.8 × 1524.0 mm (42.00 × 60.00 in)
1117.6 × 1574.8 mm (44.00 × 62.00 in)
329.0 × 558.0 mm (12.95 × 21.97 in)
300.0 × 900.0 mm (11.81 × 35.43 in)
203.2 × 203.2 mm (8.00 × 8.00 in) - 1118.0 × 1600.0 mm (44.02 × 62.99 in)
Dimensions
