9
C H A P T E R

Storage Devices

This chapter includes information about how to remove and replace the system's
internal storage devices and related cables.
"Hard Disk Drive" on page 1
"CD-ROM Drive" on page 5
"Diskette Drive" on page 8
"Internal SCSI Data Cable" on page 14
"Peripherals DC Power Harness" on page 19
"Diskette Data Cable" on page 25
"CD-ROM Audio Cable" on page 27
9.1

Hard Disk Drive

The SPARCstation 5 system accommodates 535-Mbyte, and 1.05- and 2.0-Gbyte hard
disk drives. All the drives have a single connector that connects to the SCSI
backplane in the system unit chassis. A specially designed handle, fastened to the
drive, speeds drive removal and installation.
Note – Do not remove the handle from the hard drive. It is part of the customer-
replaceable unit (CRU).
FIGURE 9-1
shows the location of the drives.
9-1
