Figure 11-2 Opening The Sbus Card Retainers - Sun Microsystems SPARCstation 5 Model 110 Service Manual

Push back both
card retainers.
Opening the SBus Card Retainers
FIGURE 11-2
4. Remove the SBus card extractor from the replacement SBus card:
a. Bend one leg of the extractor slightly to the outside until the hook clears the
hole in the SBus card.
See .
FIGURE 11-3
b. Remove the other side of the extractor, which should come out easily without
bending it.
Place the replacement SBus card on an antistatic surface.
Chapter 11 System Board and Component Replacement 11-3
