1
10
11
FIGURE 4-1
TABLE 4-2
TABLE 4-2
Pin
1
2
3
4
5
6
7
8
9
1. All volts are direct current.
4-4
SPARCstation 5 Model 110 Service Manual • November 1996
2
3 4 5 6
7
8
9
12
1314
15
16
17
18
Power Supply Connector
shows the pin assignments on the power supply connector.
Power Supply Connector Pin Assignments
Color
Description
Blue
+12V
Brown
–12V
Red
+5V
Red
+5V
Red
+5V
Red
+5V
Red
+5V
Red
+5V
Grey
Power off
1
Pin
Color
10
Black
11
Black
12
Black
13
Black
14
Black
15
Black
16
Green
17
Purple
18
Yellow
Description
Ground
Ground
Ground
Ground
Ground
Ground
AC Outlet
Fan
Power on
