12. Reinstall the CD-ROM drive (if necessary).
See Section 9.2.2 "Replacing the CD-ROM Drive."
13. Detach the wrist strap and replace the cover.
See Chapter 7.
14. Reconnect all external cables to the rear panel.
15. Power on the system.
See Section 6.2 "Powering On the System."
9.6

Diskette Data Cable

9.6.1

Removing the Diskette Data Cable

1. Shut down and power off the system.
See Section 6.1 "Powering Off the System."
2. Remove the cover and attach a wrist strap.
See Chapter 7.
3. Remove the CD-ROM drive (if present).
See Section 9.2.1 "Removing the CD-ROM Drive."
4. Remove the diskette drive.
See Section 9.3.1 "Removing the Diskette Drive."
5. Unplug the diskette data cable from the system board.
See
FIGURE 9-24
6. Carefully note how the diskette data cable is routed, and then remove it from the
system chassis.
.
Chapter 9 Storage Devices 9-25
