Attaching The Wrist Strap; Figure 7-2 Removing The Cover - Sun Microsystems SPARCstation 5 Model 110 Service Manual

FIGURE 7-2
5. Attach a wrist strap to your wrist and to the metal casing of the power supply.
See Section 7.2 "Attaching the Wrist Strap."
Caution – When you are finished servicing parts inside the system unit, be sure to
close the system unit before turning on the power. It is not safe to operate the system
unit while it is open.
7.2

Attaching the Wrist Strap

1. Unwrap the first two folds of the wrist strap and wrap the adhesive side securely
around your wrist.
See
FIGURE 7-3
Removing the Cover
.
Chapter 7 Internal Access 7-3
