Input/Output Connectors; Scsi Connector (External; Figure B-1 External Scsi Connector - Sun Microsystems SPARCstation 5 Model 110 Service Manual

B
A P P E N D I X

Input/Output Connectors

This appendix contains pinouts and illustrations of the SPARCstation 5 system
input/output (I/O) connectors. The following connectors are described.
"SCSI Connector (External)" on page 1
"Parallel Port Micro-D Connector" on page 2
"Attachment Unit Interface (AUI) Micro-D Connector" on page 3
"Twisted-Pair Ethernet Connector" on page 4
"Serial Connector Ports A and B" on page 5
"Keyboard/Mouse Connector" on page 6
"Audio Ports" on page 7
"13W3 Video Connector" on page 8
B.1

SCSI Connector (External)

25
50
FIGURE B-1
TABLE B-1
Pin
1
2
3
4
External SCSI Connector
1
Pinout Signals for External SCSI Connector
Description
Ground
Ground
Ground
Ground
Pin Description
19 Ground
20 Ground
21 Ground
22 Ground
1
26
Pin Description
37 Ground
38 Termpower
39 Ground
40 Ground
B-1
