B.6
Keyboard/Mouse Connector
8
5
FIGURE B-6
TABLE B-6
Pin
1
2
3
4
Note – All signals are standard TTL levels. The +5V supply is fuse-protected.
B-6
SPARCstation 5 Model 110 Service Manual • November 1996
7
6
4
3
2
1
Keyboard/Mouse Connector
Pinout for Keyboard/Mouse Connector
Description
Ground
Ground
+5 Vdc
Mouse In
Pin
Description
5
Keyboard Out
6
Keyboard In
7
Power Key In
8
+5 Vdc
