This connector is used to connect the system audio output to a stereophonic
amplifier and external loudspeakers.
B.7.3

Audio Line-In Connector

FIGURE B-10
This connector is used to connect external stereophonic sound sources such as a
compact disc player or cassette tape player to the system.
B.7.4

Microphone Connector

FIGURE B-11
This connector is used to connect the SunMicrophone™ II (or other suitable
microphone) to the system.
Note – The SPARCstation 5 microphone port accepts stereophonic input; however,
the SunMicrophone II is a monophonic device. Note also that the older
SunMicrophone is not compatible with the SPARCstation 5 system.
B.8

13W3 Video Connector

FIGURE B-12
and functions are described in
frame buffer card.
B-8 SPARCstation 5 Model 110 Service Manual • November 1996
Audio Line-in Connector
Microphone Connector
shows a 13W3 video connector. The 13W3 connector's pin assignments
TABLE B-8
. The connector is built into the SBus or S24
