Attachment Unit Interface (Aui) Micro-D Connector; Figure B-3 Attachment Unit Interface (Aui) Micro-D Connector; Table B-3 Pinout For Attachment Unit Interface (Aui) Micro-D Connector - Sun Microsystems SPARCstation 5 Model 110 Service Manual

TABLE B-2
Pin
5
6
7
8
9
10
11
12
13
B.3 Attachment Unit Interface (AUI) Micro-
D Connector
13
26
FIGURE B-3
TABLE B-3
Pin
1
2
3
4
5
6
7
8
9
Pinout for Parallel Port Micro-D Connector
Description
Data[3]
Data[4]
Data[5]
Data[6]
Data[7]
Ack_out_l
Busy_out_l
Pe_in
Select_out
1
14

Attachment Unit Interface (AUI) Micro-D Connector

Pinout for Attachment Unit Interface (AUI) Micro-D Connector
Description
Transmit -
Receive +
Collision -
Power
N/C
N/C
N/C
N/C
N/C
Pin Description
18 Ground
19 Ground
20 Ground
21 Ground
22 Ground
23 Ground
24 Ground
25 Ground
26 Ground
Pin Description
14 Transmit +
15 Receive -
16 Collision +
17 Ground
18 N/C
19 N/C
20 N/C
21 N/C
22 N/C
Appendix B Input/Output Connectors B-3
