B.7

Audio Ports

FIGURE B-7
TABLE B-7
Tip
Ring (Center)
Shield
B.7.1

Headphone Connector

FIGURE B-8
This connector is used to connect a set of stereophonic headphones to the system for
private listening of audio output.
B.7.2

Audio Line-Out Connector

FIGURE B-9
Audio Ports
Signals for the SPARCstation 5 Audio Ports
Headphone Line-Out
Left Channel Left Channel
Right Channel Right Channel
Ground Ground
Headphone Connector
Audio Line-out Connector
Line-In
Left Channel
Right Channel
Ground
Appendix B Input/Output Connectors
Microphone (new)
Left Channel
Right Channel
Ground
B-7
