Legend
1 – AC On/Standby switch
2 – AC power outlet
3 – Lock block
4 – SBus
5 – SBus or AFX Bus
6 – AC power receptacle
1 2
6
FIGURE 1-3
1.2

Internal Options

TABLE 1-1
TABLE 1-1
Option
S24 card
SBus cards
Hard disk drives
1-4 SPARCstation 5 Model 110 Service Manual • November 1996
7 – SCSI
8 – Parallel
9 – AUI Ethernet
10 – Twisted-pair Ethernet
11 – Serial port B
12 – Serial port A
3
7 8
Rear View of SPARCstation 5 System
lists the internal options.
Internal Options
Quantity
1
Up to 3
1 or 2
9 10 11
Comments
Provides accelerated 24-bit color graphics on the
system AFX Bus.
System board provides up to three SBus slots
for additional system functionality.
System supports up to two disk drives of
varying capacities. See Chapter 9 for more
information.
13 – Keyboard
14 – Audio, headphone
15 – Audio, line out
16 – Audio, line in
17 – Audio, microphone
4 5
14 16
12 13 15 17
