Chapter 2
This section describes how to connect a library containing two
tape drives to two SCSI buses, as shown in the following figure.
Terminator
Drive 2
50
Library
connectors
SCSI cable
connector
Tape drive connectors
Connect the host SCSI cable to the library SCSI connector.
SCSI cables to the library, tighten the SCSI cable
jack screw s to no more than 2.0 inch-pounds
(2.3 kg-cm) of torque.
Terminator
If you are connecting w ide (68-pin)
SCSI cable
connector
Jumper cable
Drive 1
Exabyte 230D
