Chapter 9
Cycle The robot moves to the home
Vertical position on the vertical axis (the
Axis axis on which the robot moves up
and down). Then, it moves to the
top of the vertical axis.
Cycle Drum From a home position, the drum
rotates 180 degrees clockwise and
then 180 degrees counter-clockwise
to complete the rotation.
Cycle The solenoid that controls the door
Solenoid locking mechanism extends and
retracts to lock and unlock the
library door.
162
Press to begin the test (the
default is 10 cycles) or press
to select the number of
cycles you want to run.
Press to begin the test (the
default is 10 cycles) or press
to select the number of
cycles you want to run. You will
hear a click each time the solenoid
extends and retracts.
