Shipping the Library
Insert the upper foam packing piece so that it is positioned
horizontally across the inside of the library, as shown in the
figure. (If necessary, adjust the position of the robot so that it
fits inside the space in the foam packing piece.)
Attach the cable clip, which is connected to the string on the
left side of upper foam packing piece, to the robot's vertical
pulley belt as shown in the figure below.
String
Cable
clip
Packing
foam
Robot
Installation and Operation
255
