Chapter 5
100
Open the library door, as described on
Remove the cartridge magazine by pulling it out first from the
top, then the bottom. You can access back magazines by
rotating the drum manually.
If desired, replace the cartridges (described on
Position the magazine so that the single mounting guide on
the magazine is aligned with the roller on the mounting plate,
as shown in the figure. Clip the magazine onto the bottom and
snap it into place by pressing on the top.
page 98.
page 99).
Exabyte 230D
