Exabyte 230D Library Installation And Operation Manual page 224

Chapter 11
You can view Ethernet information, such as the FTP user name
and password from the Ethernet Information screen on the
console interface.
Before accessing the console interface, you must set up the
following hardware and software environment:
210
Host computer that uses an RS232 serial port.
A straight-through 9-pin serial cable (not a null modem cable).
Software that supports ANSI 3.64 terminal protocol and
XMODEM data transfer protocol, such as CHS Terminal (see
the table on page 191
If necessary, connect the serial cable to the library and the host
computer (see page
Make sure the library's baud rate matches the host baud rate
(see page 193).
From your host computer, access the software you are using
to communicate with the library (for example, CHS Terminal).
for additional software settings).
192).
Exabyte 230D
