Induction of the cleaning solution
VIII.2
VIII.2.1 Pour 150 to 200 cc of cleaning solution into each ink tank.
Pour 150 to 200 cc of cleaning solution into each of the four ink tanks (C, M, Y, K).
150 to 200 cc guideline amount: The level where the filter in the ink tank is covered.
VIII.2.2 Turn on the printer power supply.
The ink pump operates to feed the cleaning solution to the sub tanks.
If the "No ink" alarm sounds, from the main menu, select [Ink Status] and then press the ENTER key.
The alarm will stop sounding when the four sub tanks (C, M, Y, K) are filled with cleaning solution. At
this time there will be no operating noise from the ink pump.
VIII.2.3 Move the printhead carriage to the cleaning position.
(1) From the main menu, select [Cleaning Tool] and then press the ENTER key.
(2) From the submenu, select [Clean Post] and then press the ENTER key.
(3) The printhead carriage moves to the cleaning position and then stops.
VIII.2.4 Feed out any cleaning solution through the PrintHead nozzles.
Press the Ink button to feed out any cleaning solution through the PrintHead nozzles.
Continue to feed the cleaning solution through the PrintHead nozzles until they are clean
(approximately 20 seconds).
Moisturizing of print head
VIII.3
See "User's Manuals; 12-2 Maintenance of print head, 1.Moisturizing of print head"
VIII.3.1 Put a clean unwoven fabric on the sponge of wet keeping frame.
VIII.3.2 Drop some cleaning solution on the unwoven fabric.
VIII.3.3 Cover the wet keeping frame the print head.
VIII.3.4 Wrap the print head unit with fresh keeping polyethylene film.
