Open the front panel.
Remove the cover from grooved poles.
(2) Remove the fixer.
(3) Attach the four inlet tubes provided to the 3-way valves on the printhead carriage.
CAUTION: Make sure that the tubes are firmly connected to the 3-way valve.
SignJet JS310 Series Set Up Guide
- 29 -
Slide the cover and remove it.
Fixer:
Remove the screws and
then remove the fixer.
Remove the screws
Inlet tube
