If you transport the printer, please dispose the ink from the printer by the procedures that are described at
the section VIII.1 Dispose the ink from the printer, then fill the ink tube and the printhead by the
cleaning solution by the procedures that are described at the section VIII.2 Induction of the cleaning
solution. After that, please dispose the cleaning solution by following procedures and transport the
printer.
Dispose the cleaning solution from the printer
IX.1
IX.1.1 Move the printhead carriage to the cleaning position.
(1) From the main menu, select [Cleaning Tool] and then press the ENTER key.
(2) From the submenu, select [Clean Post] and then press the ENTER key.
(3) The printhead carriage moves to the cleaning position and then stops.
IX.1.2 Turn off the printer power supply.
IX.1.3 Empty out the cleaning solution from the ink tanks and the solution tank.
CAUTION: First of all, remove the waste ink tanks mounted in the printer, and then discard the
IX.1.4 Empty out the cleaning solution from the sub tanks.
CAUTION: First of all, remove the waste ink tanks mounted in the printer, and then discard the
(1) Remove the cap from each sub tank.
If the cap is difficult to remove, use pliers or similar to grip the cap and open it.
(2) Empty out the cleaning solution from each sub tank.
(3) Close the cap, and replace each sub tank.
IX.1.5 Turn on the printer power supply.
The ink pump operates to feed out the any cleaning solution remaining in the tubes to the sub tanks.
When the "No ink" alarm sounds, from the main menu, select [Ink Status] and then press the ENTER
key to continue the cleaning solution removal operation.
Continue feeding out the cleaning solution until the "No ink" alarm sounds once again.
IX.1.6 Turn off the printer power supply.
IX.1.7 Empty out the cleaning solution from the sub tanks once more.
SignJet JS310 Series Set Up Guide
IX
cleaning solution from the ink tanks and the solution tank into the waste ink tanks.
cleaning solution from the sub tanks into the waste ink tanks.
