(5) Set the rotation direction switch on the media feeding system to the direction opposite to the
direction set earlier.
Inside wound media: [
(6) Rewind the media manually.
Set the selector switch on the media feeding system to the "｜" (Manual) position, rewind the
media to the position where the orange LED does not light, and then return the selector switch to
the position between the "║" and "｜" markings (the OFF position).
(7) Check that the orange LED does not light even if an object is placed behind it.
Empty core
Sensor
Check that the orange
LED does not light even if
an object is placed
behind the sensor.
(8) Check that the media stops at the sensor after it has been fed automatically.
Set the selector switch on the media feeding system to "║" (Auto).
SignJet JS310 Series Set Up Guide
] direction
- 49 -
Outside wound media: [
Media
Feeding roller
to check the sensor.
Left-hand position
] direction
Place an object here
