VII.8.3
Use the Try utility to adjust the spacing between printheads of a different color.
Follow the procedure described below to align the magenta lines with the cyan lines.
(1) On the menu bar, click File → Print Setup.
(2) Click the "More" button.
(3) The "Warning: Change these parameters carefully!" message is displayed. Click "Yes".
(4) Adjust the Horizontal Space and Vertical Space of Important Setup menu to align the magenta
lines with the cyan lines.
(5) Increase or decrease the setting values until the magenta lines are aligned on top of the cyan
lines.
VII.8.4
Print the adjustment pattern once again and check the results of the adjustments made.
Repeat the printing and adjustment procedures until all the colors are aligned.
VII.8.5
Make adjustments for the yellow and black printheads in the same way.
SignJet JS310 Series Set Up Guide
- 67 -
Adjust the vertical space
for the head of magenta.
Adjust the horizontal space for the
front head and rear head of magenta.
At this time, increase and decrease the
adjustment value of a front head and
rear head at equal value.
−
＋
Adjust the magenta line to on the cyan line.
＋ −
