V.1.3 Pour 150 to 200 cc of cleaning solution into each ink tank.
Pour 150 to 200 cc of cleaning solution into each of the four ink tanks (C, M, Y, K).
150 to 200 cc guideline amount: The level where the filter in the ink tank is covered.
V.1.4 Feed the cleaning solution to the sub tanks.
From the main menu, select [Ink Status] and then press the ENTER key. The "No ink" alarm sounds
and then stops, and the ink pump operates to feed the cleaning solution to the sub tanks.
If the "No ink" alarm sounds once again, from the main menu, select [Ink Status] and then press the
ENTER key once more. The alarm will stop sounding when the four sub tanks (C, M, Y, K) are filled
with cleaning solution. At this time there will be no operating noise from the ink pump.
Visually check that the sub tanks are sufficiently filled with cleaning solution.
The tanks should be filled up to approximately the level indicated by the white line.
V.1.5 Turn off the printer power supply.
V.1.6 Remove the printhead carriage cover.
Open the panel in front of the cleaning position, and then remove the printhead carriage cover.
Cleaning position
(Open the front panel by raising the top half and lowering the bottom half.)
