III.4.3 Menu Structure
The menu structure includes main menus and submenus. Main menus followed by "+"s have
submenus inside. Submenus followed by "−"s have no lower level inside.
The main menu items are shown below:
—> 1. Ink Status
2. Heat Status
3. Cleaning Tool +
4. Print Para
5. Application
6. Engineer Set
Press the ▲▼ keys to scroll the menus upward and downward. Press ENTER to unwrap
submenus. For example, while the arrow points to "1. Ink Status", press ENTER to unwrap the
submenu. The LCD displays details of submenu M1 as shown below:
On the LCD, M1 stands for this submenu under main menu No.1. To return the display to the
main menu, press the ESC key.
The arrow points to the first line on the LCD. Scroll the submenus by pressing the ▲ and ▼ keys
in the same way as for the main menu. A submenu followed by "−"s means that it has no lower
submenu inside. Press the ENTER key to execute the operation. To cancel the operation, press
the ESC key.
III.4.4 Setting the Numeric Values
Use the following procedures to set numeric values within the submenus.
Press the ◄ or ► key to move the cursor position over the number string.
Press the ▲ or ▼ key to increase or decrease the number value.
SignJet JS310 Series Set Up Guide
+
+
+
+
+
MENU → Ink Status
M1 Ch A C M Y K c m
Rn_ _ _ _ _ _ _
OFFLINE A1_ _ _ _ _ _ _
