Screw
V.1.7
Remove the printhead protector.
Pull and then turn
about 90 degrees.
V.1.8
Connect the inlet tubes.
(1) Remove the cover.
SignJet JS310 Series Set Up Guide
Remove
- 28 -
Printhead carriage cover:
Remove the screws at the
left and right sides and
then remove the cover.
Screw
Pull and then turn
about 90 degrees.
Open the rear panel.
Remove the screws
