GRAPHTEC SignJet JS310 Series Setup Manual page 52

(5) Return the take-up roller to its original position.
VI.2.2 Feed the media up to the take-up roller position.
(1) Set the take-up roller selector switch to the position between the "║" and "｜" markings (the OFF
position).
(2) From the main menu, select [Print Para] and then press the ENTER key.
(3) From the submenu, select [Print Post] and then press the ENTER key.
(4) While holding down the FUNC key, press the ▼ key to feed the media.
(5) When the media has reached the take-up roller position, with a little extra length added to
facilitate the take-up operation, release the keys.
SignJet JS310 Series Set Up Guide
- 51 -
Use these two screws to
fasten the flange.
Center position
