Main Unit
III.1
(6)
(9)
(10)
(1) LCD Control Panel
(2) Press roller control pole
(3) Ink tanks & Solution tank
(4) DRYER Power Socket
(5) Take-up Roller
(6) Vacuum Cleaner
(7) Media Feeding Roller
(8) Waste Ink Tanks
(9) PRINTER Power Socket & HEATER Power Socket
(10) Media Feeding System
SignJet JS310 Series Set Up Guide
- 10 -
III
Product Configuration
