(2) Aligning the vertical lines
Use the Try utility to make adjustments so that the vertical lines are perfectly aligned in the
vertical direction.
On the menu bar, click File → Print Setup.
Click the "More" button.
The "Warning: Change these parameters carefully!" message is displayed. Click "Yes".
Change the settings in accordance with the printed results.
The line printed by the
print head of rear.
The line printed by the
print head of front.
Adjust these values to move horizontal
printing position of the front print head.
Increasing the value:
Print position is moved to right.
Decreasing the value:
Print position is moved to left.
