Setting the Print Speed
IV.5
IV.5.1 Turn on the printer power supply.
When the power is turned on, the printer begins a self-test operation (the printhead carriage and the
feed rollers move). When the self test has been completed, wait until the main menu is displayed on
the LCD.
Since ink has not yet been supplied to the printer, a "No Ink" alarm will sound after several
minutes have elapsed. This alarm does not indicate a malfunction, and no action is required.
IV.5.2 Set the printhead carriage speed.
(1) From the main menu, select [Print Para] and then press the ENTER key.
(2) From the submenu, select [Print Speed] and then press the ENTER key.
(3) Select "Norm", and then press the ENTER key.
(4) Return to the main menu.
IV.5.3 Set the media feed speed.
(1) From the main menu, select [Print Para] and then press the ENTER key.
(2) From the submenu, select [Feed Speed] and then press the ENTER key.
(3) Select "Norm", and then press the ENTER key.
(4) Return to the main menu.
Executing the Moving Test
IV.6
Execute the Moving Test to ensure that the lubricating oil is spread evenly on the printhead carriage
rails and the feed rollers.
If the power is turned off, turn it on.
Since ink has not yet been supplied to the printer, a "No Ink" alarm will sound after several
minutes have elapsed. This alarm does not indicate a malfunction, and no action is required.
IV.6.1 Execute the Moving Test.
(1) From the main menu, select [Engineer Set] and then press the ENTER key.
(2) From the submenu, select [Moving Test] and then press the ENTER key.
IV.6.2 Let the operation continue for approximately 15 minutes.
Check that there are no abnormalities during the moving test operation.
If there are any abnormalities such as an unusual noise or if the printer doesn't operate, turn off the
power supply and contact your sales representative or nearest Graphtec vendor.
IV.6.3 End the Moving Test.
Press the ESC key to end the moving test. When the test has ended, return to the main menu.
Hold down the ESC key until the printhead carriage stops at the Home position.
