8.5.2.3

USB Configuration Submenu

Feature
xHCI Mode
SSIC Support Enable
SSIC Init Sequence
SSIC Port 1
SSIC Port 2
HSIC Port 1
HSIC Port 2
USB2 PHY Power Gating
USB3 PHY Power Gating
USB OTG Support
8.5.2.4

PCI Express Configuration Submenu

Feature
► PCIE Express Root Port 1
► PCIE Express Root Port 2
► PCIE Express Root Port 3
► PCIE Express Root Port 4
► PCIE Express S0ix Settings
Native PCI Express Support
Copyright © 2016 congatec AG
Options Description
Enabled Mode of xHCI controller operation.
Disabled
Disabled Enable or disable SSIC support.
Enabled
SSIC Initialization Sequence 1 Select sequence 1 for Windows.
SSIC Initialization Sequence 2 Select sequence 2 for Android.
Enabled Enable or disable SSIC port 1.
Disabled
Enabled Enable or disable SSIC port 2.
Disabled
Enabled Enable or disable HSIC port 1.
Disabled
Enabled Enable or disable HSIC port 2.
Disabled
Auto Select USB2 PHY power gating.
Disabled
Enabled
Auto Select USB3 PHY power gating.
Disabled
Enabled
PCI Mode Enable or disable USB OTG support.
Disabled
Options Description
Submenu
Submenu
Submenu
Submenu
Submenu
Disabled Enable or disable native operating system PCIe support
Enabled
