Nvme Submenu; Sdio Submenu; Usb Submenu - Congatec conga-IA4 User Manual

Feature
Delay Time
Error Message Report
Summary Screen
Delay Time
8.4.23

NVMe Submenu

Feature
NVMe controller and Drive Information
8.4.24

SDIO Submenu

Feature
SDIO Access Mode
8.4.25

USB Submenu

Feature
USB Module Version
USB Controllers
USB Devices
Legacy USB Support
xHCI Hand-off
Copyright © 2016 congatec AG
Options Description
0 - 10 Set POST report time in seconds or to wait until ESC key is pressed.
Until Press ESC
Disabled Enable or disable error message support.
Enabled
Disabled Enable or disable summary screen.
Enabled
0 - 10 Set summary screen from 0 to 10 seconds or select to wait till ESC key is pressed.
Until Press ESC
Options
No option
Options Description
Auto 'Auto Option' - Access SD device in DMA mode if controller supports it, otherwise in PIO mode.
ADMA 'MDA Option' - AccessSD device in DMA mode.
SDMA 'PIO Option' - Access SD device in PIO mode.
PIO
Options Description
No option Displays the version of the USB module.
No option Displays the available USB controllers.
No option Displays the detected USB devices.
Enabled
'Enable' - Enables legacy USB support.
Disabled 'Disable' - Keeps USB devices available only for EFI applications and BIOS setup.
Auto 'Auto' - Disables legacy support if no USB devices are connected.
Enabled This is a workaround for operating systems without xHCI hand-off support.
Disabled
Note: If this feature is enabled, the xHCI ownership change should be claimed by xHCI operating system driver.
Description
IA40m12.indd 77/97
